- Place of Origin: SHANDONG
- Brand Name: SHENGYUAN
- Model Number: Semi-Trailer
- :
Place of Origin | Shandong province, China |
Color and logo | Color & logo available |
Rated Load | 60 ton |
Wheel Base | 1310 (mm) |
Tire specification | 12.00R20 ,14 PR Radio tire |
Axles | 13Tonnage ,3 axles,FUWA /BPW optional |
Pieces of leaf-spring | 10pcs,-/10/10/10 |
Outside Dimensions (LxWxH) | 12450X2500X1580(mm) |
Floor | 3mm management plate |
High side wall | 800mm |
Tool Box | 1 box of standard tools |
Spare tire carrier | 2 sets |
Color and Logo | Depends on your requirements |
The Traction pin(King pin) | 2 inch 3.5 inch inter-changeable |
Brake System | Dual Lines Braking System With Automatic Air Chambers |
Electrical System | 24v.7 core socket,lights according to European standards |
Pin Height | According to the height of the tractor saddle. |
Brake Air Chamber | Four Double and two single chamber |
Main Beam Material | Q345B/ST25-3 manganese plates,automatic submerged arc, Main-beam Height 500mm, Through cross beams Q235,side Beam :160mm Upper flange:14mm,Mid web:8mm,lower flange:16mm |
Painting | Sand blasting processing on rust-proof protection. One coat of anticorrosive primer, two coats of finish urethane paint, Color as customer choice. Crylic acid or polyurethane painting |
FAQ
| 1.What Certifications we have ? | |
| we have got the CCC,ISO,SGS,CQC,BV etc.certifications. | |
| 2.Is the brand of trailer parts available: | |
We have domestic parts and the axle brand you may choose FUWA ,BPW, for landing gear brand JOST,here have two kinds of speed to for your reference,Single acting leg,and two speed led. | |
| 3.Truck head can we provide? | |
Yes,if you need our semi trailer,we will provide you truck head as full set truck. the brand of truck tractor may be brand FAW ,brand HOWO. that the 4*2 truck head,6*4 truck head and so on. | |
| 4.Will we provide After-sale services: | |
We you need our trailer parts in using our trailers,we will provide you them, only charge the cost of producing them,and delivery fees. 5.Will you provide engineer for special trailers after sale? we will peovide you our engineer to your country if you need,and also can talk with engineers via online contacts like whatsapp,at imo or wechat.we will do our best ,now,and forever.
we have warranty of the parts list in the sheet below: Item NameWarrantyItem NameWarrantyMain FrameFrame12 MonthsRunning GearAxles6 MonthsKing Pin12 MonthsTires6 MonthsSuspension6 MonthsAxle Bear3 MonthsBalance Arm3 MonthsWheel Hub3 MonthsItem NameWarrantyItem NameWarrantyBraking DeviceAir Reservoir6 MonthsSupport DeviceLanding Gear6 MonthsBraking Chamber3 MonthsSpare Wheel Carrier6 MonthsBraking Drum3 MonthsItem NameWarrantyOther ItemLeaf Spring3 MonthsBrake ShoeRelay ValveEmergency Relay ValveBrake Chamber Diaphragm
|
